Documentation

Exporting project data

To export a Kili project from Kili UI, follow the steps in Exporting labels from Kili UI. For the formats you can export to, refer to Export formats.

To export labels programmatically, refer to the Kili SDK documentation and the Kili CLI documentation. The SDK and Kili UI produce the same files for the same format and parameters.

Exporting labels from Kili UI

  1. From the project Queue page, select the assets that you want to export. The Quick actions menu appears above the asset list.
  2. From the Quick actions menu, select Export.
  3. In the "Export data" window, set your export parameters, then click Export.
  4. Wait for the notification in the top-right corner of the screen, then download the archive.
📘

If you exported labels from this project before, you can select Select from previous to download one of the previous export archives instead of creating a new one.

Export parameters

In the "Export data" window, you can set:

  • Format: the label format. Only the formats that fit your project's labeling jobs are listed. Refer to Export formats.
  • Bounding boxes (YOLO v5 to YOLO26 only): how bounding boxes are written. Refer to YOLO formats.
  • Scope: which labels of each asset are exported. Refer to Scope of exported labels.
  • Layout (YOLO and COCO formats): whether the archive holds one folder per labeling job (One label per asset for each job) or a single dataset grouping all jobs (One label per asset grouping all jobs).

Export formats

FormatExported annotationsDetails
Kili API formatAll jobs and annotation typesKili data format
YOLO v5 to YOLO26Bounding boxes, polygons, semantic segmentationYOLO formats
YOLO v4Bounding boxesYOLO formats
COCOBounding boxes, polygons, semantic segmentationCOCO format
Pascal VOCBounding boxesPascal VOC format

A format is listed in the "Export data" window only when your project has at least one job it can export: a bounding box job for YOLO v4 and Pascal VOC, and a bounding box, polygon or semantic segmentation job for YOLO v5 to YOLO26 and COCO.

YOLO, COCO and Pascal VOC exports skip the annotations they can't represent (points, lines, pose estimation, classification, transcription) instead of failing. To export these, use the Kili API format.

📘

From the SDK, you can also export to formats that aren't available in Kili UI, such as GeoJSON. For details, refer to the Kili SDK documentation.

Scope of exported labels

  • Latest label (for each asset): the most recent label of each asset, the one you can trust for your model.
  • Latest labels from each author (for each asset): the most recent label of each labeler, for each asset.

When an asset has several exported labels, YOLO exports write one label file per label, suffixed _label1, _label2, and so on, next to a single copy of the image.

Content of the export archive

Every archive contains a README.kili.txt file with:

  • Project name
  • Project identifier
  • Project description
  • Export date
  • Exported format
  • Scope of exported labels

The rest of the archive depends on the format. Refer to each format's page.

🚧

If your project uses a cloud storage integration, the archive contains labels only, not the assets. A remote_assets.csv file lists each asset's external ID, URL and label file.

Learn more

For an end-to-end example of exporting labels with the Kili Python SDK, refer to the tutorial on exporting project data.
